Kubernetes 块模式 PV

Oct 6, 2022 15:00 · 3142 words · 7 minute read Kubernetes Container Linux

Kubernetes 通过 volumeMode 字段支持 Filesystem（默认）和 Block 两种模式的持久化卷（PersistentVolume）：

  • Filesystem（文件系统）

    apiVersion: v1
kind: PersistentVolumeClaim
metadata:
name: myclaim
spec:
accessModes:
- ReadWriteOnce
volumeMode: Filesystem
resources:
    requests:
    storage: 8Gi
storageClassName: fast

  • Block（块）

    apiVersion: v1
kind: PersistentVolumeClaim
metadata:
name: myclaim
spec:
accessModes:
- ReadWriteOnce
volumeMode: Block
resources:
    requests:
    storage: 8Gi
storageClassName: fast

Filesystem 模式的存储卷会以文件目录的形式挂载进 Pod。如果存储卷背后是一个空的块设备，Kubernetes 在挂载前会先在块设备上创建一个文件系统。将 volumeMode 的值设置为 Block，存储卷会作为一个裸块设备来使用，在 Pod 中表现为没有文件系统的一个块设备。本文只探讨 Block 模式的 PersistentVolume（简写为 PV）在容器中表现为一个块设备的实现原理和底层技术细节。

涉及组件较多：

  • 后端存储：OpenEBS v0.9.0
  • Kubernetes：v1.23.6
  • CRI 容器运行时：containerd v1.6.2
  • OCI 容器运行时：runc v1.1.0

Pod 如何使用块模式的 PV 请自行查看官方文档 https://kubernetes.io/docs/concepts/storage/persistent-volumes/#pod-specification-adding-raw-block-device-path-in-container。

下文件中出现的 CSI_DIR 变量为 /var/lib/kubelet/plugins/kubernetes.io/csi/volumeDevices 路径

$ kubectl exec -it virt-launcher-ecs-test13-wzvx6 -n ns-demo -- ls -al /dev/heredatadisk
brw------- 1 qemu qemu 253, 4 Sep 23 07:52 /dev/heredatadisk

virt-launcher-ecs-test13-wzvx6 Pod 所使用的 PV 在容器中表现为 /dev/heredatadisk 块设备文件，major（主设备号）为 253，用于定位设备驱动程序；minor（次设备号）为 4，作为参数传给驱动程序，选择相应的单元。

我们顺着 Kubernetes 在节点上创建 Pod 的流程来梳理整个过程，当 Pod 被成功调度后：

CSI 部分

  1. OpenEBS 的 CSI node plugin，即 openebs-lvm-node DaemonSet Pod 在宿主机上创建 LVM 逻辑卷 /dev/lvmvg/pvc-aa9d7716-d027-438a-8d76-c95b46a31ce1

    $ lsblk /dev/sdd
NAME                                                  MAJ:MIN RM SIZE RO TYPE MOUNTPOINT
sdd                                                     8:48   0  60G  0 disk
└─lvmvg-pvc--aa9d7716--d027--438a--8d76--c95b46a31ce1 253:3    0  10G  0 lvm

$ ll /dev/lvmvg/pvc-aa9d7716-d027-438a-8d76-c95b46a31ce1
lrwxrwxrwx 1 root root 7 Sep 26 09:57 /dev/lvmvg/pvc-aa9d7716-d027-438a-8d76-c95b46a31ce1 -> ../dm-3
$ ll /dev/dm-3
brw-rw---- 1 root disk 253, 4 Oct  6 13:03 /dev/dm-3

    /dev/dm-3 块设备文件的主次设备号分别为 253 和 4，它的上一层路径 /dev 则是以 devtmpfs 的这个特殊的“文件系统”挂载到宿主机上的：

    $ mount -l | grep "/dev "
devtmpfs on /dev type devtmpfs (rw,nosuid,size=16327076k,nr_inodes=4081769,mode=755)

    实际上 /dev/dm-3 块设备文件也很特殊，其 inode 不关联存储介质数据，只与驱动建立连接。

  2. CSI node plugin 创建目标文件 $CSI_DIR/publish/pvc-aa9d7716-d027-438a-8d76-c95b46a31ce1/47ad9107-5e1a-4a27-b8d1-1e21b6ed0f12 https://github.com/openebs/lvm-localpv/blob/v0.9.0/pkg/lvm/mount.go#L241

    // MountBlock mounts the block disk to the specified path
func MountBlock(vol *apis.LVMVolume, mountinfo *MountInfo, podLVInfo *PodLVInfo) error {
    target := mountinfo.MountPath
    volume := vol.Spec.VolGroup + "/" + vol.Name
    devicePath := DevPath + volume

    mountopt := []string{"bind"}

    mounter := &mount.SafeFormatAndMount{Interface: mount.New(""), Exec: utilexec.New()}

    // Create the mount point as a file since bind mount device node requires it to be a file
    err := makeFile(target)
    if err != nil {
        return status.Errorf(codes.Internal, "Could not create target file %q: %v", target, err)
    }
    // a lot of code here
}

// https://github.com/openebs/lvm-localpv/blob/v0.9.0/pkg/lvm/mount.go#L301-L313
func makeFile(pathname string) error {
    f, err := os.OpenFile(pathname, os.O_CREATE, os.FileMode(0644))
    defer func(f *os.File) {
        err = f.Close()
        klog.Errorf("failed to close file %s error: %v", f.Name(), err)
    }(f)
    if err != nil {
        if !os.IsExist(err) {
            return err
        }
    }
    return nil
}

    该文件遵循 CSI 规范，为 Kubernetes Pod 所用。

  3. CSI node plugin 将 /dev/lvmvg/pvc-aa9d7716-d027-438a-8d76-c95b46a31ce1 bind mount 至新创建的文件 $CSI_DIR/publish/pvc-aa9d7716-d027-438a-8d76-c95b46a31ce1/47ad9107-5e1a-4a27-b8d1-1e21b6ed0f12 https://github.com/openebs/lvm-localpv/blob/v0.9.0/pkg/lvm/mount.go#L247

    func MountBlock(vol *apis.LVMVolume, mountinfo *MountInfo, podLVInfo *PodLVInfo) error {
    target := mountinfo.MountPath
    volume := vol.Spec.VolGroup + "/" + vol.Name
    devicePath := DevPath + volume

    mountopt := []string{"bind"}
    // a lot of code here
    // do the bind mount of the device at the target path
    if err := mounter.Mount(devicePath, target, "", mountopt); err != nil {
        if removeErr := os.Remove(target); removeErr != nil {
            return status.Errorf(codes.Internal, "Could not remove mount target %q: %v", target, removeErr)
        }
        return status.Errorf(codes.Internal, "mount failed at %v err : %v", target, err)
    }
    // a lot of code here
}

  4. bind mount 后 $CSI_DIR/publish/pvc-aa9d7716-d027-438a-8d76-c95b46a31ce1/47ad9107-5e1a-4a27-b8d1-1e21b6ed0f12 文件的类型变成了 block，而“文件系统”则变成了 devtmpfs。

    $ ll /var/lib/kubelet/plugins/kubernetes.io/csi/volumeDevices/publish/pvc-aa9d7716-d027-438a-8d76-c95b46a31ce1/47ad9107-5e1a-4a27-b8d1-1e21b6ed0f12
brw-rw---- 1 root disk 253, 3 Sep 26 09:57 /var/lib/kubelet/plugins/kubernetes.io/csi/volumeDevices/publish/pvc-aa9d7716-d027-438a-8d76-c95b46a31ce1/47ad9107-5e1a-4a27-b8d1-1e21b6ed0f12

$ mount -l | grep /var/lib/kubelet/plugins/kubernetes.io/csi/volumeDevices/publish/pvc-aa9d7716-d027-438a-8d76-c95b46a31ce1/47ad9107-5e1a-4a27-b8d1-1e21b6ed0f12
devtmpfs on /var/lib/kubelet/plugins/kubernetes.io/csi/volumeDevices/publish/pvc-aa9d7716-d027-438a-8d76-c95b46a31ce1/47ad9107-5e1a-4a27-b8d1-1e21b6ed0f12 type devtmpfs (rw,nosuid,size=16327076k,nr_inodes=4081769,mode=755)

    注意到 $CSI_DIR/publish/pvc-aa9d7716-d027-438a-8d76-c95b46a31ce1/47ad9107-5e1a-4a27-b8d1-1e21b6ed0f12 的主次设备号与 LVM 逻辑卷 /dev/lvmvg/pvc-aa9d7716-d027-438a-8d76-c95b46a31ce1 相同，它们背后是同一个设备。

再看一眼 virt-launcher Pod 中的挂载表：

kubectl exec -it virt-launcher-ecs-test13-qqpt2 -n ns-demo -- mount -l
overlay on / type overlay (rw,relatime,lowerdir=/var/lib/containerd/io.containerd.snapshotter.v1.overlayfs/snapshots/10648/fs:/var/lib/containerd/io.containerd.snapshotter.v1.overlayfs/snapshots/10647/fs:/var/lib/containerd/io.containerd.snapshotter.v1.overlayfs/snapshots/10646/fs,upperdir=/var/lib/containerd/io.containerd.snapshotter.v1.overlayfs/snapshots/11651/fs,workdir=/var/lib/containerd/io.containerd.snapshotter.v1.overlayfs/snapshots/11651/work)
proc on /proc type proc (rw,nosuid,nodev,noexec,relatime)
tmpfs on /dev type tmpfs (rw,nosuid,size=65536k,mode=755)

/dev 在容器中是以 tmpfs 挂载出来的，而宿主机上则是 devtmpfs，后面会说到。

CRI 部分

1. kubelet

Kubernetes 在创建容器（Pod）时，将容器内的块文件 /dev/heredatadisk（由 Pod 对象定义）与宿主机上块设备文件 $CSI_DIR/publish/pvc-aa9d7716-d027-438a-8d76-c95b46a31ce1/47ad9107-5e1a-4a27-b8d1-1e21b6ed0f12 的映射关系封装入 CRI 容器创建请求中 https://github.com/kubernetes/kubernetes/blob/v1.23.6/pkg/kubelet/kubelet_pods.go#L110-L141：

func (kl *Kubelet) makeBlockVolumes(pod *v1.Pod, container *v1.Container, podVolumes kubecontainer.VolumeMap, blkutil volumepathhandler.BlockVolumePathHandler) ([]kubecontainer.DeviceInfo, error) {
    var devices []kubecontainer.DeviceInfo
    for _, device := range container.VolumeDevices {
        // check path is absolute
        if !filepath.IsAbs(device.DevicePath) {
            return nil, fmt.Errorf("error DevicePath `%s` must be an absolute path", device.DevicePath)
        }
        vol, ok := podVolumes[device.Name]
        if !ok || vol.BlockVolumeMapper == nil {
            klog.ErrorS(nil, "Block volume cannot be satisfied for container, because the volume is missing or the volume mapper is nil", "containerName", container.Name, "device", device)
            return nil, fmt.Errorf("cannot find volume %q to pass into container %q", device.Name, container.Name)
        }
        // Get a symbolic link associated to a block device under pod device path
        dirPath, volName := vol.BlockVolumeMapper.GetPodDeviceMapPath()
        symlinkPath := path.Join(dirPath, volName)
        if islinkExist, checkErr := blkutil.IsSymlinkExist(symlinkPath); checkErr != nil {
            return nil, checkErr
        } else if islinkExist {
            // Check readOnly in PVCVolumeSource and set read only permission if it's true.
            permission := "mrw"
            if vol.ReadOnly {
                permission = "r"
            }
            klog.V(4).InfoS("Device will be attached to container in the corresponding path on host", "containerName", container.Name, "path", symlinkPath)
            devices = append(devices, kubecontainer.DeviceInfo{PathOnHost: symlinkPath, PathInContainer: device.DevicePath, Permissions: permission})
        }
    }

    return devices, nil
}

反向追溯在 kubelet 中该过程的调用链：makeBlockVolumes <- kubelet.GenerateRunContainerOptions <- generateContainerConfig.generateContainerConfig <- kubeGenericRuntimeManager.startContainer

func (m *kubeGenericRuntimeManager) startContainer(podSandboxID string, podSandboxConfig *runtimeapi.PodSandboxConfig, spec *startSpec, pod *v1.Pod, podStatus *kubecontainer.PodStatus, pullSecrets []v1.Secret, podIP string, podIPs []string) (string, error) {
    // a lot of code here
    containerConfig, cleanupAction, err := m.generateContainerConfig(container, pod, restartCount, podIP, imageRef, podIPs, target)
    if cleanupAction != nil {
        defer cleanupAction()
    }

    containerID, err := m.runtimeService.CreateContainer(podSandboxID, containerConfig, podSandboxConfig)
    if err != nil {
        s, _ := grpcstatus.FromError(err)
        m.recordContainerEvent(pod, container, containerID, v1.EventTypeWarning, events.FailedToCreateContainer, "Error: %v", s.Message())
        return s.Message(), ErrCreateContainer
    }
    // a lot of code here
}

kubelet 通过 gRPC 将容器创建请求发送至容器运行时 containerd。

2. containerd

containerd 接收到 kubelet 的容器创建请求后首先生成默认挂载 https://github.com/containerd/containerd/blob/v1.6.2/oci/spec.go#L132-L197：

func populateDefaultUnixSpec(ctx context.Context, s *Spec, id string) error {
    ns, err := namespaces.NamespaceRequired(ctx)
    if err != nil {
        return err
    }

    *s = Spec{
    }
    s.Mounts = defaultMounts()
    return nil
}

func defaultMounts() []specs.Mount {
    return []specs.Mount{
        {
            Destination: "/proc",
            Type:        "proc",
            Source:      "proc",
            Options:     []string{"nosuid", "noexec", "nodev"},
        },
        {
            Destination: "/dev",
            Type:        "tmpfs",
            Source:      "tmpfs",
            Options:     []string{"nosuid", "strictatime", "mode=755", "size=65536k"},
        },
        // a lot of code here
    }
}

容器内 /dev 使用 tmpfs 挂载是 runc 即 libcontainerd 的规范。

而 /dev/heredatadisk 也作为 ContainerPath 封装入 OCI 容器结构体中 https://github.com/containerd/containerd/blob/v1.6.2/oci/spec_opts_linux.go#L285-L328：

func WithDevices(osi osinterface.OS, config *runtime.ContainerConfig, enableDeviceOwnershipFromSecurityContext bool) oci.SpecOpts {
    return func(ctx context.Context, client oci.Client, c *containers.Container, s *runtimespec.Spec) (err error) {
        // a lot of code here
        for _, device := range config.GetDevices() {
            path, err := osi.ResolveSymbolicLink(device.HostPath)
            if err != nil {
                return err
            }

            o := oci.WithDevices(path, device.ContainerPath, device.Permissions)
            if err := o(ctx, client, c, s); err != nil {
                return err
            }
        }
        // a lot of code here
    }
}

// https://github.com/containerd/containerd/blob/v1.6.2/oci/spec_opts_linux.go#L39-L61
func WithDevices(devicePath, containerPath, permissions string) SpecOpts {
    return func(_ context.Context, _ Client, _ *containers.Container, s *Spec) error {
        devs, err := getDevices(devicePath, containerPath)
        if err != nil {
            return err
        }
        for i := range devs {
            s.Linux.Devices = append(s.Linux.Devices, devs[i])
            s.Linux.Resources.Devices = append(s.Linux.Resources.Devices, specs.LinuxDeviceCgroup{
                Allow:  true,
                Type:   devs[i].Type,
                Major:  &devs[i].Major,
                Minor:  &devs[i].Minor,
                Access: permissions,
            })
        }
        return nil
    }
}

getDevices -> DeviceFromPath

func DeviceFromPath(path string) (*specs.LinuxDevice, error) {
    var stat unix.Stat_t
    if err := unix.Lstat(path, &stat); err != nil {
        return nil, err
    }

    var (
        devNumber = uint64(stat.Rdev) //nolint: unconvert // the type is 32bit on mips.
        major     = unix.Major(devNumber)
        minor     = unix.Minor(devNumber)
    )
}


func Lstat(path string, stat *Stat_t) (err error) {
    return Fstatat(AT_FDCWD, path, stat, AT_SYMLINK_NOFOLLOW)
}

通过 lstat 函数即 fstatat 系统调用获得 $CSI_DIR/publish/pvc-aa9d7716-d027-438a-8d76-c95b46a31ce1/47ad9107-5e1a-4a27-b8d1-1e21b6ed0f12 对应的主次设备号 253 和 4。

containerd 的容器创建请求（配置）通过容器 rootfs 上一层目录下的 config.json 文件传递给 OCI 容器运行时也就是 runc：

$ ll /run/containerd/io.containerd.runtime.v2.task/k8s.io/06d9182a20cab4de567357f3af1d24201e8093e66fb37c50153f82f3b2a56669/
total 24
-rw-r--r-- 1 root root   89 Sep 26 10:18 address
-rw-r--r-- 1 root root 7242 Sep 26 10:18 config.json
-rw-r--r-- 1 root root    5 Sep 26 10:18 init.pid
prwx------ 1 root root    0 Sep 26 10:18 log
-rw-r--r-- 1 root root    0 Sep 26 10:18 log.json
-rw------- 1 root root    2 Sep 26 10:18 options.json
drwxr-xr-x 1 root root   74 Sep 26 10:18 rootfs
-rw------- 1 root root    0 Sep 26 10:18 runtime
-rw------- 1 root root   38 Sep 26 10:18 shim-binary-path
lrwxrwxrwx 1 root root  121 Sep 26 10:18 work -> /var/lib/containerd/io.containerd.runtime.v2.task/k8s.io/06d9182a20cab4de567357f3af1d24201e8093e66fb37c50153f82f3b2a56669

$ cat /run/containerd/io.containerd.runtime.v2.task/k8s.io/06d9182a20cab4de567357f3af1d24201e8093e66fb37c50153f82f3b2a56669/config.json
        "devices":[
            {
                "path":"/dev/kvm",
                "type":"c",
                "major":10,
                "minor":232,
                "fileMode":438,
                "uid":0,
                "gid":36
            },
            {
                "path":"/dev/net/tun",
                "type":"c",
                "major":10,
                "minor":200,
                "fileMode":438,
                "uid":0,
                "gid":0
            },
            {
                "path":"/dev/vhost-net",
                "type":"c",
                "major":10,
                "minor":238,
                "fileMode":384,
                "uid":0,
                "gid":0
            },
            {
                "path":"/dev/bootdisk",
                "type":"b",
                "major":252,
                "minor":16,
                "fileMode":432,
                "uid":0,
                "gid":6
            },
            {
                "path":"/dev/heredatadisk",
                "type":"b",
                "major":253,
                "minor":3,
                "fileMode":432,
                "uid":0,
                "gid":6
            }
        ],

其中 /dev/bootdisk 与主次设备号（major 253; minor 3）在同一个数据结构中。

OCI

最后来到 OCI 容器运行时 runc。

追溯创建容器时的调用链 prepareRootfs -> createDevices -> createDeviceNode -> mknodDevice

  • createDevices：

    func createDevices(config *configs.Config) error {
    useBindMount := userns.RunningInUserNS() || config.Namespaces.Contains(configs.NEWUSER)
    oldMask := unix.Umask(0o000)
    for _, node := range config.Devices {

        // The /dev/ptmx device is setup by setupPtmx()
        if utils.CleanPath(node.Path) == "/dev/ptmx" {
            continue
        }

        // containers running in a user namespace are not allowed to mknod
        // devices so we can just bind mount it from the host.
        if err := createDeviceNode(config.Rootfs, node, useBindMount); err != nil {
            unix.Umask(oldMask)
            return err
        }
    }
    unix.Umask(oldMask)
    return nil
}

  • createDeviceNode

    func createDeviceNode(rootfs string, node *devices.Device, bind bool) error {
    if node.Path == "" {
        // The node only exists for cgroup reasons, ignore it here.
        return nil
    }
    dest, err := securejoin.SecureJoin(rootfs, node.Path)
    if err != nil {
        return err
    }
    if err := os.MkdirAll(filepath.Dir(dest), 0o755); err != nil {
        return err
    }
    if bind {
        return bindMountDeviceNode(rootfs, dest, node)
    }
    if err := mknodDevice(dest, node); err != nil {
        if errors.Is(err, os.ErrExist) {
            return nil
        } else if errors.Is(err, os.ErrPermission) {
            return bindMountDeviceNode(rootfs, dest, node)
        }
        return err
    }
    return nil
}

  • mknodDevice

    func mknodDevice(dest string, node *devices.Device) error {
    fileMode := node.FileMode
    switch node.Type {
    case devices.BlockDevice:
        fileMode |= unix.S_IFBLK
    case devices.CharDevice:
        fileMode |= unix.S_IFCHR
    case devices.FifoDevice:
        fileMode |= unix.S_IFIFO
    default:
        return fmt.Errorf("%c is not a valid device type for device %s", node.Type, node.Path)
    }
    dev, err := node.Mkdev()
    if err != nil {
        return err
    }
    if err := unix.Mknod(dest, uint32(fileMode), int(dev)); err != nil {
        return &os.PathError{Op: "mknod", Path: dest, Err: err}
    }
    return os.Chown(dest, int(node.Uid), int(node.Gid))
}

// https://github.com/opencontainers/runc/blob/v1.1.1/libcontainer/devices/device_unix.go#L23-L28
func mkDev(d *Rule) (uint64, error) {
    if d.Major == Wildcard || d.Minor == Wildcard {
        return 0, errors.New("cannot mkdev() device with wildcards")
    }
    return unix.Mkdev(uint32(d.Major), uint32(d.Minor)), nil
}

本质上是通过 mknod 系统调用在容器内的 /dev 下创建块设备文件 heredatadisk，这个设备文件通过主次设备号（major 253; minor 3）控制设备驱动程序操作设备，即宿主机上的 LVM 逻辑卷设备 /dev/lvmvg/pvc-aa9d7716-d027-438a-8d76-c95b46a31ce1。

总结

创建容器的过程是由多个组件串联而成的，从 kubelet 到 containerd 到 runc，组件与组件的通信之间由各种规范（CSI、CRI、OCI）定义接口。容器内的块设备文件，归根到底还是由 OCI 容器运行时 mknod 块设备文件，文件关联的主次设备号，则是由一些列的 gRPC 甚至文件层层传递而来。
