Ingress Nginx 实现原理
May 7, 2021 21:00 · 2062 words · 5 minute read
Ingress 是将 Kubernetes 集群中服务对外暴露的一种 API 对象。
一个最小化的 Ingress 对象（Kubernetes v1.19+）：
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
name: minimal-ingress
annotations:
nginx.ingress.kubernetes.io/rewrite-target: /
spec:
rules:
- http:
paths:
- path: /testpath
pathType: Prefix
backend:
service:
name: test
port:
number: 80
Kubernetes v1.19+ 版本的 Ingress API 定义与之前有所不同。
| Kubernetes 版本 | Ingress API 版本 |
|---|---|
| v1.5 - v1.17 | extensions/v1beta1 |
| v1.8 - v1.18 | networking.k8s.io/v1beta1 |
| v1.19+ | networking.k8s.io/v1 |
要正常使用 Ingress，必须首先在 Kubernetes 集群中部署 Ingress Controller。
kubectl apply -f https://raw.githubusercontent.com/kubernetes/ingress-nginx/controller-v0.46.0/deploy/static/provider/cloud/deploy.yaml
kubectl get po -n ingress-nginx
NAME READY STATUS RESTARTS AGE
ingress-nginx-admission-create-6764l 0/1 Completed 0 13m
ingress-nginx-admission-patch-jlhrn 0/1 Completed 0 13m
ingress-nginx-controller-57cb5bf694-shflg 1/1 Running 0 13m
然后部署一个 flask demo app:
$ kubectl apply -f https://raw.githubusercontent.com/crazytaxii/kubernetes-extra/master/deploy/flask-demo/all.yaml
$ cat <<EOF >flask-ingress.yaml
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
name: flask-ingress
annotations:
nginx.ingress.kubernetes.io/rewrite-target: /
spec:
rules:
- http:
paths:
- path: /
pathType: Prefix
backend:
service:
name: flask-service
port:
number: 80
EOF
$ kubectl apply -f flask-ingress.yaml -n flask-demo
$ kubectl get svc -n ingress-nginx
NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
ingress-nginx-controller LoadBalancer 10.107.230.163 <pending> 80:31787/TCP,443:31913/TCP 54m
ingress-nginx-controller-admission ClusterIP 10.100.9.152 <none> 443/TCP 54m
$ curl http://10.211.55.62:31787
<html><head><title>Docker + Flask Demo</title></head><body><table><tr><td> Start Time </td> <td>2021-May-07 07:53:17</td> </tr><tr><td> Hostname </td> <td>flask-deployment-68c5b8bb95-fzzw4</td> </tr><tr><td> Local Address </td> <td>10.244.0.9</td> </tr><tr><td> Remote Address </td> <td>10.244.0.8</td> </tr><tr><td> Server Hit </td> <td>1</td> </tr></table></body></html>
现在我们就可以通过主机 IP + NodePort 来访问部署在 Kubernetes 集群中的服务了。
下面我们来探索 Ingress Controller 也就是 openresty 如何将流量导向集群中的 app 容器。
ingress controller 在 Kubernetes 集群中以 ingress-nginx 命名空间中的 ingress-nginx-controller-57cb5bf694-shflg Pod 形式运行，无论是 nginx 还是 openresty 都有一份基础配置即 /etc/nginx/nginx.conf 文件：
$ kubectl exec ingress-nginx-controller-57cb5bf694-shflg -n ingress-nginx -- cat /etc/nginx/nginx.conf
http {
lua_package_path "/etc/nginx/lua/?.lua;;";
lua_shared_dict balancer_ewma 10M;
lua_shared_dict balancer_ewma_last_touched_at 10M;
lua_shared_dict balancer_ewma_locks 1M;
lua_shared_dict certificate_data 20M;
lua_shared_dict certificate_servers 5M;
lua_shared_dict configuration_data 20M;
lua_shared_dict global_throttle_cache 10M;
lua_shared_dict ocsp_response_cache 5M;
resolver 10.96.0.10 valid=30s ipv6=off;
upstream upstream_balancer {
### Attention!!!
#
# We no longer create "upstream" section for every backend.
# Backends are handled dynamically using Lua. If you would like to debug
# and see what backends ingress-nginx has in its memory you can
# install our kubectl plugin https://kubernetes.github.io/ingress-nginx/kubectl-plugin.
# Once you have the plugin you can use "kubectl ingress-nginx backends" command to
# inspect current backends.
#
###
server 0.0.0.1; # placeholder
balancer_by_lua_block {
balancer.balance()
}
}
## start server _
server {
server_name _ ;
listen 80 default_server reuseport backlog=511 ;
listen 443 default_server reuseport backlog=511 ssl http2 ;
location / {
set $namespace "flask-demo";
set $ingress_name "flask-ingress";
set $service_name "flask-service";
set $service_port "80";
set $location_path "/";
set $global_rate_limit_exceeding n;
rewrite_by_lua_block {
lua_ingress.rewrite({
force_ssl_redirect = false,
ssl_redirect = true,
force_no_ssl_redirect = false,
use_port_in_redirects = false,
global_throttle = { namespace = "", limit = 0, window_size = 0, key = { }, ignored_cidrs = { } },
})
balancer.rewrite()
plugins.run()
}
set $proxy_upstream_name "flask-demo-flask-service-80";
set $proxy_host $proxy_upstream_name;
set $pass_access_scheme $scheme;
set $pass_server_port $server_port;
set $best_http_host $http_host;
set $pass_port $pass_server_port;
proxy_pass http://upstream_balancer;
}
}
## end server _
# default server, used for NGINX healthcheck and access to nginx stats
server {
listen 127.0.0.1:10246;
set $proxy_upstream_name "internal";
location /configuration {
client_max_body_size 21m;
client_body_buffer_size 21m;
proxy_buffering off;
content_by_lua_block {
configuration.call()
}
}
location / {
content_by_lua_block {
ngx.exit(ngx.HTTP_NOT_FOUND)
}
}
}
}
因为配置文件内容很长这里就只贴关键部分。proxy_pass 反向代理设置为 upstream_balancer，而 upstream_balancer 中出现了 openresty 中应用层负载均衡的语法 balancer_by_lua_block { lua-script }。
lua_package_path "/etc/nginx/lua/?.lua;;" 表示 lua 脚本在 /etc/nginx/lua 路径下，我们直接去找 ingress-nginx 这个项目的源码仓库 https://github.com/kubernetes/ingress-nginx/tree/controller-v0.46.0 并找到 balancer.balance() 函数的定义 https://github.com/kubernetes/ingress-nginx/blob/controller-v0.46.0/rootfs/etc/nginx/lua/balancer.lua#L311-L335：
function _M.balance()
local balancer = get_balancer()
if not balancer then
return
end
local peer = balancer:balance()
if not peer then
ngx.log(ngx.WARN, "no peer was returned, balancer: " .. balancer.name)
return
end
if peer:match(PROHIBITED_PEER_PATTERN) then
ngx.log(ngx.ERR, "attempted to proxy to self, balancer: ", balancer.name, ", peer: ", peer)
return
end
ngx_balancer.set_more_tries(1)
local ok, err = ngx_balancer.set_current_peer(peer)
if not ok then
ngx.log(ngx.ERR, "error while setting current upstream peer ", peer,
": ", err)
end
end
balancer 对象由 get_balancer() 函数获取到：
local function get_balancer()
local backend_name = ngx.var.proxy_upstream_name -- flask-demo-flask-service-80
local balancer = balancers[backend_name]
if not balancer then
return
end
ngx.ctx.balancer = balancer
return balancer
end
在配置文件 /etc/nginx/nginx.conf 中 proxy_upstream_name 这个 nginx 变量已经被设置为 flask-demo-flask-service-80 了，那我们就要找到写 balancers 全局 table 相关的代码 https://github.com/kubernetes/ingress-nginx/blob/controller-v0.46.0/rootfs/etc/nginx/lua/balancer.lua#L107-L139：
local function sync_backend(backend)
if not backend.endpoints or #backend.endpoints == 0 then
balancers[backend.name] = nil
return
end
local implementation = get_implementation(backend)
local balancer = balancers[backend.name]
if not balancer then
balancers[backend.name] = implementation:new(backend)
return
end
-- every implementation is the metatable of its instances (see .new(...) functions)
-- here we check if `balancer` is the instance of `implementation`
-- if it is not then we deduce LB algorithm has changed for the backend
if getmetatable(balancer) ~= implementation then
ngx.log(ngx.INFO,
string.format("LB algorithm changed from %s to %s, resetting the instance",
balancer.name, implementation.name))
balancers[backend.name] = implementation:new(backend)
return
end
balancer:sync(backend)
end
而 sync_backend 又在 sync_backends() 函数中遍历 new_backends table 时被循环调用：
local function sync_backends()
local backends_data = configuration.get_backends_data()
if not backends_data then
balancers = {}
return
end
local new_backends, err = cjson.decode(backends_data)
if not new_backends then
ngx.log(ngx.ERR, "could not parse backends data: ", err)
return
end
local balancers_to_keep = {}
for _, new_backend in ipairs(new_backends) do
if is_backend_with_external_name(new_backend) then
local backend_with_external_name = util.deepcopy(new_backend)
backends_with_external_name[backend_with_external_name.name] = backend_with_external_name
else
sync_backend(new_backend)
end
balancers_to_keep[new_backend.name] = true
end
end
首先调用 configuration.get_backends_data() 得到所有后端数据：
function _M.get_backends_data()
return configuration_data:get("backends")
end
这个 key 为 backend 的值在 configuration.handle_backends() 函数调用后就已经被预先插入了：
local function handle_backends()
if ngx.var.request_method == "GET" then
ngx.status = ngx.HTTP_OK
ngx.print(_M.get_backends_data())
return
end
local backends = fetch_request_body()
if not backends then
ngx.log(ngx.ERR, "dynamic-configuration: unable to read valid request body")
ngx.status = ngx.HTTP_BAD_REQUEST
return
end
end
local function fetch_request_body()
ngx.req.read_body()
local body = ngx.req.get_body_data()
if not body then
-- request body might've been written to tmp file if body > client_body_buffer_size
local file_name = ngx.req.get_body_file()
local file = io.open(file_name, "rb")
if not file then
return nil
end
body = file:read("*all")
file:close()
end
return body
end
看着像读取 HTTP 请求应答的数据，但这里看不出来对应的 HTTP 请求，全局搜索 handle_backends()，找到了 call() 函数：
function _M.call()
-- a lot of code here
if ngx.var.request_uri == "/configuration/backends" then
handle_backends()
return
end
ngx.status = ngx.HTTP_NOT_FOUND
ngx.print("Not found!")
end
这条 HTTP 请求的路径为 /configuration/backends，/configuration 这个路径在 nginx 配置中看到过：
location /configuration {
client_max_body_size 21m;
client_body_buffer_size 21m;
proxy_buffering off;
content_by_lua_block {
configuration.call()
}
}
我们在 Ingress Controller Pod 也就是 ingress-nginx-controller-57cb5bf694-shflg 容器中手动 curl 一把：
kubectl exec ingress-nginx-controller-57cb5bf694-shflg -n ingress-nginx -- curl -s http://127.0.0.1:10246/configuration/backends
[{"name":"flask-demo-flask-service-80","service":{"metadata":{"creationTimestamp":null},"spec":{"ports":[{"name":"http","protocol":"TCP","port":80,"targetPort":5000}],"selector":{"app":"flask"},"clusterIP":"10.109.208.21","type":"ClusterIP","sessionAffinity":"None"},"status":{"loadBalancer":{}}},"port":80,"sslPassthrough":false,"endpoints":[{"address":"10.244.0.10","port":"5000"},{"address":"10.244.0.11","port":"5000"},{"address":"10.244.0.9","port":"5000"}],"sessionAffinityConfig":{"name":"","mode":"","cookieSessionAffinity":{"name":""}},"upstreamHashByConfig":{"upstream-hash-by-subset-size":3},"noServer":false,"trafficShapingPolicy":{"weight":0,"header":"","headerValue":"","headerPattern":"","cookie":""}},{"name":"upstream-default-backend","port":0,"sslPassthrough":false,"endpoints":[{"address":"127.0.0.1","port":"8181"}],"sessionAffinityConfig":{"name":"","mode":"","cookieSessionAffinity":{"name":""}},"upstreamHashByConfig":{},"noServer":false,"trafficShapingPolicy":{"weight":0,"header":"","headerValue":"","headerPattern":"","cookie":""}}]
flask-demo 相关的数据赫然在列，拿到集群中所有 backends 数据后，sync_backends 函数将遍历 backend 列表，以 name 字段的值为 table 的 key，插入 implementation:new(backend) 对象。如果没有特殊设置，这里的 implementation 就是 round_robin 负载均衡算法 https://github.com/kubernetes/ingress-nginx/blob/controller-v0.46.0/rootfs/etc/nginx/lua/balancer/round_robin.lua#L9-L19：
function _M.new(self, backend)
local nodes = util.get_nodes(backend.endpoints)
local o = {
instance = self.factory:new(nodes),
traffic_shaping_policy = backend.trafficShapingPolicy,
alternative_backends = backend.alternativeBackends,
}
setmetatable(o, self)
self.__index = self
return o
end
function _M.balance(self)
return self.instance:find()
end
一切都渐渐明朗起来了，backend.endpoints 也就是三个 flask pod 的 Pod IP 与端口，get_nodes 函数在 util.lua 文件中定义 https://github.com/kubernetes/ingress-nginx/blob/controller-v0.46.0/rootfs/etc/nginx/lua/util.lua#L16-L26
function _M.get_nodes(endpoints)
local nodes = {}
local weight = 1
for _, endpoint in pairs(endpoints) do
local endpoint_string = endpoint.address .. ":" .. endpoint.port
nodes[endpoint_string] = weight
end
return nodes
end
我们回到上面的 balancer.lua 文件，当 get_balancer() 获取到 balancer 对象后，调用 balancer:balance() 函数将返回 self.instance:find()，从三个 endpoints 中挑出一个返回。
这也就是通过 Ingress 访问 Kubernetes 集群中的服务时，负载均衡器代理的是 Pod IP 而不是 Cluster IP 的原理。
