在 AWS EC2 上部署高可用 Kubernetes 集群

Sep 3, 2019 21:00 · 1279 words · 3 minute read Kubernetes Docker CentOS

两种方案 https://kubernetes.io/docs/setup/production-environment/tools/kubeadm/ha-topology/：

  1. 堆叠 etcd 拓扑，在 master 节点上托管 etcd 集群
  2. 外置 etcd 集群，etcd 与 master 节点分离，显然需要更多的机器

经费在燃烧🥺这里采用堆叠 etcd 拓扑也就是第一种。

集群架构与设施（AWS）

  • VPC 10.0.0.0/16
  • 子网
    subnet CIDR 路由表
    sub1 10.0.0.0/24 custom
    sub2 10.0.1.0/24 main
  • 网关
    • Internet 网关
    • NAT 网关（选中 sub1 子网，需要分配弹性 IP）
  • 配置路由表
    • main
      Destination Target
      10.0.0.0/16 local
      0.0.0.0/0 NAT 网关
    • custom
      Destination Target
      10.0.0.0/16 local
      0.0.0.0/0 Internet 网关
  • 实例（推荐 3 master 节点 3+ worker 节点）
    hostname 私有 IP 公有 IP OS
    bastion 10.0.0.100 3.114.12.155 CentOS
    kube-master-1 10.0.1.100 CentOS
    kube-master-2 10.0.1.101 CentOS
    kube-master-3 10.0.1.102 CentOS
    kube-worker-1 10.0.1.200 CentOS
    kube-worker-2 10.0.1.201 CentOS
  • 负载均衡器（必须使用）
    • 内部使用
    • VPC 选中 sub2
    • 添加侦听器 TCP 6443 端口
    • 目标组选择 IP 10.0.1.100（master0）

需要确保负载均衡器只路由到 master0 上的 6443 端口。这是因为 kubeadm 将使用负载均衡器 IP 执行健康检查。由于 master0 是第一个单独配置的，其他 master 不会运行 apiserver，这将导致 kubeadm 无限期地挂起。

部署前准备（手动或者使用 Ansible 来完成）

1. Docker

安装 Docker

yum install -y yum-utils \
    device-mapper-persistent-data \
    lvm2
yum-config-manager \
    --add-repo \
    https://download.docker.com/linux/centos/docker-ce.repository
yum install -y docker-ce

配置 Docker 使用 systemd 作为默认 Cgroup 驱动

cat <<EOF > /etc/docker/daemon.json
{
    "exec-opts": ["native.cgroupdriver=systemd"]
}
EOF

启动 Docker 并使其开机自启

systemctl start docker
systemctl enable docker

2. Kubernetes 全家桶

安装 Kubernetes 相关应用程序并使 kubelet 开机自启

cat <<EOF > /etc/yum.repos.d/kubernetes.repo
[kubernetes]
name=Kubernetes
baseurl=https://packages.cloud.google.com/yum/repos/kubernetes-el7-x86_64
enabled=1
gpgcheck=1
repo_gpgcheck=1
gpgkey=https://packages.cloud.google.com/yum/doc/yum-key.gpg https://packages.cloud.google.com/yum/doc/rpm-package-key.gpg
exclude=kube*
EOF
setenforce 0 # disable SELinux
sudo sed -i 's/^SELINUX=enforcing$/SELINUX=permissive/' /etc/selinux/config
yum install -y kubelet kubeadm kubectl --disableexcludes=kubernetes
systemctl enable --now kubelet

关闭系统交换区

swapoff -a
sed -i '/ swap / s/^\(.*\)$/#\1/g' /etc/fstab

或者使用 kubeadm-ansible 完成部署前准备🚀

部署高可用集群

初始化 master0 节点

与单主节点集群部署不同，需要先编写 Kubeadm 的配置文件：

$ cat kubeadm-config.yaml
apiVersion: kubeadm.k8s.io/v1beta2
kind: ClusterConfiguration
kubernetesVersion: stable
controlPlaneEndpoint: "${LOAD_BALANCER_DNS}:6443"
networking:
  podSubnet: ${CIDR}
  • kubernetesVersion 设置想要使用的 Kubernetes 版本，推荐使用 stable
  • controlPlaneEndpoint 设置负载均衡器的 DNS 域名或地址和端口

有些 CNI 网络插件比如 Calico 需要另外设置一个 CIDR，Weave 这样的就不需要。

sudo kubeadm init --config=kubeadm-config.yaml --upload-certs
  • --upload-certs 用来把控制节点所共享的证书上传到集群。

安装完成后 Kubeadm 的输出：

Your Kubernetes control-plane has initialized successfully!

To start using your cluster, you need to run the following as a regular user:

  mkdir -p $HOME/.kube
  sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
  sudo chown $(id -u):$(id -g) $HOME/.kube/config

You should now deploy a pod network to the cluster.
Run "kubectl apply -f [podnetwork].yaml" with one of the options listed at:
  https://kubernetes.io/docs/concepts/cluster-administration/addons/

You can now join any number of the control-plane node running the following command on each as root:

  kubeadm join api-lb-574e65695cb56b54.elb.ap-northeast-1.amazonaws.com:6443 --token dum7wt.8wwa3mpfzmum1620 \
    --discovery-token-ca-cert-hash sha256:52a3719a16e2f6e2417afd0a8c8be709ec4f28442491be4c89835db47e49b2b3 \
    --control-plane --certificate-key 77d7258ce9581174082cabb9905e0e28adf3f0e8238edfa035545de8203b4b30

Please note that the certificate-key gives access to cluster sensitive data, keep it secret!
As a safeguard, uploaded-certs will be deleted in two hours; If necessary, you can use
"kubeadm init phase upload-certs --upload-certs" to reload certs afterward.

Then you can join any number of worker nodes by running the following on each as root:

kubeadm join api-lb-574e65695cb56b54.elb.ap-northeast-1.amazonaws.com:6443 --token dum7wt.8wwa3mpfzmum1620 \
    --discovery-token-ca-cert-hash sha256:52a3719a16e2f6e2417afd0a8c8be709ec4f28442491be4c89835db47e49b2b3
  • 把两个 join 命令记下来，其他节点加入集群要用到
  • 当 kubeadm init 带上 --upload-certs 时，master0 节点的证书会被加密并保存在 kubeadm-certs Secret 中

kubeadm-certs Secret 两小时后将失效😱

部署 CNI 网络插件

  • Calico kubectl apply -f https://docs.projectcalico.org/v3.8/manifests/calico.yaml
  • Flannel kubectl apply -f https://raw.githubusercontent.com/coreos/flannel/master/Documentation/kube-flannel.yml

测试 master0 节点是否正常：

kubectl get nodes
kubectl get pod -n kube-system -w

🎉🎉🎉

将其它 master 节点加入集群

执行刚才保存下来的第一段 kubeadm join 命令：

kubeadm join api-lb-574e65695cb56b54.elb.ap-northeast-1.amazonaws.com:6443 --token dum7wt.8wwa3mpfzmum1620 \
    --discovery-token-ca-cert-hash sha256:52a3719a16e2f6e2417afd0a8c8be709ec4f28442491be4c89835db47e49b2b3 \
    --control-plane --certificate-key 77d7258ce9581174082cabb9905e0e28adf3f0e8238edfa035545de8203b4b30
  • --control-plane 使 kubeadm join 创建一个新的控制节点
  • --certificate-key ... 将从集群中的 kubeadm-certs Secret 下载证书并解密

🎉🎉🎉

将其他工作节点加入集群

执行刚才保存下来的第二段 kubeadm join 命令：

kubeadm join api-lb-574e65695cb56b54.elb.ap-northeast-1.amazonaws.com:6443 --token dum7wt.8wwa3mpfzmum1620 \
    --discovery-token-ca-cert-hash sha256:52a3719a16e2f6e2417afd0a8c8be709ec4f28442491be4c89835db47e49b2b3

测试集群是否正常：

$ kubectl get nodes
NAME            STATUS   ROLES    AGE    VERSION
kube-master-1   Ready    master   142m   v1.15.3
kube-master-2   Ready    master   116m   v1.15.3
kube-master-3   Ready    master   113m   v1.15.3
kube-worker-1   Ready    <none>   31s    v1.15.3
kube-worker-2   Ready    <none>   31s    v1.15.3
$ kubectl get pods --all-namespaces
kubectl get pod -n kube-system -w
NAME                                    READY   STATUS    RESTARTS   AGE
coredns-5c98db65d4-25k5n                1/1     Running   0          3h33m
coredns-5c98db65d4-jpq5r                1/1     Running   0          3h33m
etcd-kube-master-1                      1/1     Running   0          3h32m
etcd-kube-master-2                      1/1     Running   0          3h7m
etcd-kube-master-3                      1/1     Running   0          3h4m
kube-apiserver-kube-master-1            1/1     Running   0          3h32m
kube-apiserver-kube-master-2            1/1     Running   0          3h7m
kube-apiserver-kube-master-3            1/1     Running   0          3h4m
kube-controller-manager-kube-master-1   1/1     Running   1          3h32m
kube-controller-manager-kube-master-2   1/1     Running   0          3h7m
kube-controller-manager-kube-master-3   1/1     Running   0          3h4m
kube-flannel-ds-amd64-5q77t             1/1     Running   0          3h6m
kube-flannel-ds-amd64-cz4wt             1/1     Running   0          71m
kube-flannel-ds-amd64-hd79k             1/1     Running   0          71m
kube-flannel-ds-amd64-p4c5d             1/1     Running   0          3h6m
kube-flannel-ds-amd64-pn6zk             1/1     Running   0          3h4m
kube-proxy-66jsj                        1/1     Running   0          3h33m
kube-proxy-btqnz                        1/1     Running   0          71m
kube-proxy-kwnkx                        1/1     Running   0          3h7m
kube-proxy-nfrfw                        1/1     Running   0          71m
kube-proxy-xdr9d                        1/1     Running   0          3h4m
kube-scheduler-kube-master-1            1/1     Running   1          3h32m
kube-scheduler-kube-master-2            1/1     Running   0          3h7m
kube-scheduler-kube-master-3            1/1     Running   0          3h4m

🎉🎉🎉
